Operating Precautions for Shot Blasting Machines for Welded Workpieces

Shot blasting is widely applied to optimize the welding quality of metal materials. Traditional mostly manual blasting methods suffer from low efficiency and inconsistent surface treatment quality. Shot blasting machines dedicated to welded components effectively overcome these drawbacks. Blasting treatment on metal structures remarkably smooths workpiece surfaces and removes oxide scale, greatly boosting coating adhesion.

Shot blasting machines clean and smooth the surfaces of welded steel structures, improving their weldability and simplifying subsequent processing steps. Thorough rust removal via blasting is critical for enhanced welding performance. Furthermore, this process drastically extends the service life and functional performance of finished steel structures, lifting their economic value.

If forged workpieces are welded and coated directly without prior surface preparation, poor coating adhesion will occur, which severely impairs service performance. The use of shot blasting machines for welded parts greatly eliminates such risks, delivering a clean, efficient, user-friendly high-productivity workflow. This equipment is widely adopted across industrial manufacturing, particularly in the steel structure and forging sectors.

Load the specified quantity of workpieces into the blasting chamber and close the access door before starting the machine. The workpieces rotate on roller conveyors, while the blasting turbine emits fan-shaped abrasive streams that uniformly strike all workpiece surfaces for thorough cleaning. Abrasive shot and dust fall through small holes on the conveyor belt into the bottom screw conveyor, which transports the mixture to the bucket elevator. The elevator lifts the abrasives up to the separator for classification. A fan draws dust-laden air into the dust collector, where dust is filtered out and clean air is vented to the atmosphere. Dust accumulates in the collection bin at the bottom of the dust collector and requires regular cleaning. Recyclable abrasives flow back to the blasting chamber through a recycling pipeline for repeated use after separation in the separator. All blasting angles and coverage zones are calculated via computer-aided design. The top belt conveyor shot blasting machine minimizes idle abrasive discharge to maximize abrasive utilization efficiency.
